UniFi Switch Aggregation, administrable capa 2, 8 puertos SFP+ de 10G

UniFi Switch Aggregation, administrable capa 2, 8 puertos SFP+ de 10G

USW-AGGREGATION

UBIQUITI

$ 1.396.292,63
Más IVA

(1 Unidades)

Recursos y documentación

Descargar hoja de especificaciones

10 más vendido
50 personas viendo

Cantidad

Compras sin cuenta usan el precio de lista público. Inicia sesión para precios según tu perfil.

Descripcion

Overview

Dimensions

442 x 120 x 43.7 mm (17.4 x 4.7 x 1.7')

Port Layout

10G SFP+

8 (10G/1G)

Form Factor

Rack mount (1U)

Performance

Switching Capacity

160 Gbps

Total Non-Blocking Throughput

80 Gbps

Forwarding Rate

119 Mpps

Supported VLANs

1,000

MAC Address Table Size

16,000

Packet Buffer Size

1.5 MB

Access Lists

IPv4

128

MAC

128

Layer 2 Features

LACP Port Aggregation

Yes

STP & RSTP

Yes

Advanced IGMP Configuration (Querier, Fast Leave, Router Port)

Yes

IGMP Snooping

Yes

802.1X Control

Yes

MAC-Based ACLs & Device Isolation

Yes

DHCP Snooping & Guarding

Yes

Egress Rate Limit

Yes

Flow Control

Yes

Storm Control

Yes

Multicast & Broadcast Rate Limiting

Yes

MAC Address Blocking

Yes

IP-Based ACLs & Network Isolation

Yes

MAC-Based Port Restriction

Yes

Port Isolation

Yes

Port Mirroring

Yes

Jumbo Frames

Yes

LLDP-MED

Yes

Voice VLAN

Yes

Loop Protection

Yes

Virtual Network Override

Yes

Hardware

Max. Power Consumption

36W (Including SFP modules)

Power Method

Universal input, 100—240V AC, 50/60 Hz

Power Input Method

AC input

Power Supply

AC/DC, internal, 36W

Supported Voltage Range

100—240V AC

Management

Ethernet AR

Heat Dissipation

102 BTU/hr

Weight

Without mounting brackets: 2.6 kg (5.8 lb) With mounting brackets: 2.7 kg (6 lb)

Enclosure Material

SGCC steel

Mount Material

SGCC steel

Supported Rack Depth

400~1200 mm (15.7-47.2')

LCM Display

1.3' touchscreen

ESD Protection

Air: ± 16kV, contact: ± 12kV

Ambient Operating Temperature

-5 to 40° C (23 to 104° F)

Ambient Operating Humidity

10 to 90% noncondensing

NDAA Compliant

Yes

Certifications

CE, FCC, IC, Anatel: 04456-21-08356

Software

Application Requirements

UniFi Network

Version 5.14.12 and later
